A fork positioner is actually an apparatus constructed out of top quality materials meant to endure the most difficult procedures and work environments. This piece of equipment could enable the one driving to be able to operate the forks hydraulically without leaving the seat. Side shifting units have the extra ability to laterally position the entire load or the arms in order to facilitate much more accurate lifting and placement in a faster and more efficient method.
The unique fork pocket design can enable the person operating it to securely sway the unit's blades without any worry of damaging the positioning cylinders. This can allow the worker the choice to either execute simultaneous or independent blade movement, dependent upon the requirements of the job. For most forklifts with non-OEM carriages, complete carriages are required. Standard OEM carriages can be converted into blade positioners on existing units.
Click to Download the pdf
